Premium Quality Concrete Weigh Batching Plant Model PL 1200
The PL 1200 concrete weigh batching plant ensures premium quality through precise electronic measurement of sand, stone, and cement. Its robust design supports aggregate bins with individual weighing hoppers, achieving high batching accuracy for consistent mix designs. The user-friendly control system automates feeding and weighing cycles, reducing manual errors. With durable structure and quick installation features, this model is ideal for medium to large construction sites requiring reliable, efficient, and repeatable batching performance.
Modelo :
Yixin Machinety Batching PlantEmbalaje :
FilmModo de transacción :
TT or 100%LCCantidad mínima de pedido :
1 SetColor :
yellow or white and bluePuerto de descarga: :
Xiamen PortCiencia de los materiales :
Q235 Steel ,handox steelPremium Quality Concrete Weigh Batching Plant Model PL 1200
Reference video of cocnrete batching plant machine
The PL 1200 concrete batching machine is a core component for precise aggregate handling. It automatically weighs and feeds sand, gravel, and other materials according to your specified mix design. Designed for premium quality production, this model ensures high batching accuracy, improving concrete consistency and structural strength. Its durable weighing system supports fast, reliable operation under heavy use. The PL 1200 integrates seamlessly with concrete plants, streamlining material flow and reducing waste. Ideal for construction projects demanding strict quality control, it boosts efficiency while maintaining exact recipe compliance throughout production cycles.
Tech Data
| Type | PL800 | PL1200 | PL1600-3 | PL1600-4 |
| Volume of Weigh Hopper | 2m³*2 | 4m³*3 | 7m³*3 | 7m³*4 |
| Wolume of Unloading Hopper （m³） | 0.8 | 1.2 | 1.6 | 1.6 |
| Productivity（m³） | 48 | 72 | 96 | 96 |
| Maximum Magnitude | 1.5T | 2T | 3T | 4T |
Product Detail
Product Display
The weighing system of the PL 1200 model is built around durable weighing hoppers, high-precision load cells, and intelligent control instruments. This combination guarantees exact measurement of aggregates before mixing. The system continuously monitors material weight, automatically adjusting for even minor deviations. Real-time data feedback ensures consistent batching accuracy, preventing errors in mix proportions. By maintaining strict control over each component’s quantity, the system directly supports concrete quality and structural integrity, making it vital for premium production environments.
Professional Shipping
The electrical control system of the PL1200 concrete batching plant acts as the equipment’s intelligent brain. It uses advanced microcomputer control to fully automate the weighing and batching process. The system enables precise material measurement, real-time monitoring, and efficient data management. Operators can easily track production records, adjust batch formulas, and ensure consistent mix quality. This smart control unit improves workflow reliability, reduces manual errors, and enhances overall plant productivity, making it an essential component for professional concrete production operations.
| FAQ |
| 1. What is the PL Series mainly used for?
It is used for automatic batching of sand, stone, and other aggregates in concrete production. It works well with mixers like JS series. |
|
2.Is it easy to operate?
Yes, it has a user-friendly control system. Operators can easily set formulas and monitor the process with clear displays. |
| 3.Can it handle different materials?
Yes, it can batch multiple types of aggregates like gravel, sand, and crushed stone. The configuration can be adjusted based on material needs. |
| 4. Is this a plant that requires extensive civil work and foundations, or is it designed for fast setup?
It is designed for rapid deployment. The PL Series comes in a semi-portable configuration. The main structure is pre-wired and pre-assembled at our factory. You don’t need deep, complex foundations—usually just a prepared, leveled concrete pad with anchor bolts. For a standard PL Series plant, we typically complete installation and commissioning within 10 to 14 days from the arrival of the equipment, assuming site preparation is ready. |
| 5.What about power consumption? Efficiency isn’t just about speed for us; it’s also about energy costs per cubic meter.
That’s a key metric. The high efficiency here directly reduces energy costs. We use premium-efficiency motors on the mixer and the belts. More importantly, the mixer operates with an optimal filling ratio. Because the mixing cycle is shorter than standard plants, you produce more cubic meters per kilowatt-hour. Customers typically report a 15 to 20 percent reduction in energy consumption per cubic meter compared to their older volumetric or free-fall plants. |
